Fineness of cement
The degree of fineness of cement represents the average size of the grains within it. There are three primary methods used to test the fineness of cement: the sieve method, employing a 90-micron (9 No.) sieve; the air permeability method, such as Nurse and Blains method; and the sedimentation method, such as the Wagner turbidimeter method. While the latter two methods measure surface area, the first method focuses on grain size. However, as cement grains are finer than 90 microns, the sieve analysis method may not provide a true representation of the mean grain size. Additionally, the tendency of tiny cement grains to conglomerate into lumps can distort the final grain size distribution curves. To overcome these limitations, fineness is commonly expressed in terms of specific area, representing the total surface area of particles per unit weight of material.
Factors affecting Fineness of cement
The fineness of cement is influenced by several factors, both during the manufacturing process and storage. Here are some key factors that affect the fineness of cement:
Grinding Technique: The method used to grind the raw materials and clinker into cement affects fineness. Grinding techniques and equipment can vary, impacting the particle size distribution of the final product.
Clinker Composition: The chemical composition of clinker, the primary material in cement production, influences fineness. Different clinker compositions may result in variations in cement fineness.
Grinding Duration: The duration of the grinding process directly impacts fineness. Longer grinding times typically produce finer particles, but the process needs to be balanced to avoid excessive energy consumption.
Cement Composition: Cement often contains additives such as gypsum or other materials to control setting time or enhance certain properties. These additives can affect the fineness of the cement.
Cement Storage Conditions: Improper storage conditions, such as exposure to moisture or inadequate protection from air, can cause clumps or agglomeration in the cement, altering its fineness.
Quality Control Measures: Stringent quality control measures during manufacturing help ensure consistent particle size distribution and fineness of the cement. Variations in the manufacturing process can impact the final product’s quality.
Type of Grinding Aid: Grinding aids, which are sometimes used to improve grinding efficiency, can influence the fineness of cement by affecting particle agglomeration and the overall grinding process.
Cement Particle Size Distribution: The distribution of particle sizes within the cement affects its performance. A well-graded particle size distribution contributes to better packing and improved properties of the final concrete mix.
Cement Type: Different types of cement (like Portland cement, blended cement, etc.) may have different fineness requirements or specifications based on their intended use and standards.
Importance of Fineness of cement
The importance of fineness in cement cannot be overstated. Finer cement translates to increased strength, as the larger surface area available for hydration promotes better early strength development. However, the ultimate strength remains largely unaffected. Moreover, increased fineness enhances the cohesiveness of concrete mixes, reducing water separation (bleeding) during compaction with vibrators. Yet, exceeding a certain fineness limit can compromise cement’s properties due to prehydration from atmospheric moisture. Finer cement also exhibits heightened reactions in alkali-reactive aggregates, potentially raising water requirements and workability, leading to higher drying shrinkage and cracking.The importance can be summarized as
Surface Area: Finer particles have a larger surface area per unit weight compared to coarser particles. This increased surface area allows for better interaction with water, accelerating the hydration process and enhancing the strength development of concrete.
Hydration: Cement particles need to hydrate to form a strong concrete matrix. Finer particles hydrate more quickly and efficiently because water can penetrate and react with them more effectively, leading to faster setting times and increased early strength.
Workability: Finer cement particles typically improve the workability of concrete. This means that concrete made with finer cement can be easier to place and manipulate during construction, which is beneficial for various construction applications.
Strength and Durability: Properly controlling the fineness of cement allows for the optimization of concrete strength and durability. Finer particles contribute to denser concrete, reducing the porosity and enhancing its strength and resistance to various environmental factors, such as chemical attacks and freeze-thaw cycles.
Consistency: Maintaining consistent fineness from batch to batch ensures consistent performance of the concrete mixtures. This is crucial in construction to achieve predictable and reliable results.
Want to practice MCQs on Cement?
From Portland to pozzolana, see how well you know the world of cement with our specialized MCQs.
Sieve Method
Equipment Required for Fineness test of cement by Sieve Method
IS Sieve (90 µm) with lid: This sieve, specifically designed to measure fineness, ensures that only particles smaller than 90 microns pass through. The accompanying lid helps in the sieving process.
A balance with 0.01 gm sensitivity: This precise balance is crucial for accurately measuring the weight of the cement sample.
A pure bristle or nylon brush: Used for cleaning the sieve and ensuring accurate testing by removing any residue between trials.
Sieve Shaking Machine (optional): While not mandatory, a sieve shaking machine can assist in achieving consistent and standardized sieving results by automating the shaking process, ensuring uniformity in testing.
Procedure for Fineness test of cement by Sieve Method
Sample Preparation: Measure precisely 1000 grams (1 Kg) of cement as the test sample (w1). Ensure the cement particles are free of lumps by thorough manual rubbing.
Sieve Setup: Pour the 1 Kg cement sample into the sieve and securely close it using the sieve lid.
Sieve Shaking: If available, employ a sieve shaking machine and run it for 15 minutes. This ensures consistent agitation. If a shaking machine isn’t accessible, manually shake the sieve vigorously in all directions for a minimum of 15 minutes to achieve uniformity.
Cleaning: Gently brush the sieve base using a bristle brush to remove any residue, ensuring a clean sieve surface.
Weighing: After sieving, weigh the amount of cement retained on the 90 µm sieve and record it as (w2).
Calculating Retained Percentage: Calculate the percentage of cement retained on the sieve using the formula: Percent of cement retained on sieve=(W2/W1)×100
Repeat Testing: Conduct the test a minimum of three times to minimize errors and ensure consistency in results.
Result
| Type of Cement | Percentage of Residue by Weight | Specific Surface (m²/kg) not less than |
|---|---|---|
| Ordinary Portland Cement (OPC) | 10 | 225 |
| Rapid Hardening Cement (RHC) | 5 | 325 |
| Portland Puzzolana Cement (PPC) | 5 | 300 |
Blaine’s Air Permeability Method for Assessing Cement Fineness
Blaine’s air permeability apparatus is designed to draw a specific quantity of air through a prepared bed of cement with a predetermined porosity. This method determines the fineness of the cement, expressed as the total surface area in square centimeters per gram.
Equipment Required for Fineness test of cement by Blaine’s Air Permeability Method
Instrument Specifications |
||
|---|---|---|
| Name | Range | Accuracy |
| Blaine air permeability apparatus | Refer to IS:5516 | - |
| Balance | 3 g | 1 mg |
| Timer | 30 min. | 0.2 sec |
Procedure for Fineness test of cement by Blaine’s Air Permeability Method
(a) Determination of Density of Cement:
Various methods can be employed to determine this characteristic. Click here to explore detailed procedures for measuring the density or specific gravity of cement.
(b). Determination of Bed Volume
Preparation:
- Apply a very thin film of light mineral oil to the interior of the cell.
- Place a perforated disc on the ledge within the cell and position two new filter paper discs on top of the perforated disc.
Mercury Filling:
- Fill the cell with mercury and ensure it is leveled to the brim using a glass plate.
- Carefully remove the mercury from the cell and note its weight as M1.
Cement Bed Preparation:
- Remove the top filter paper from the cell.
- Compress a trial quantity of 2.80 grams of cement above the filter paper to the gauge line within the cell.
- Place another filter paper disc over the cement bed.
Second Mercury Filling:
- Fill the remaining space in the cell above the filter paper with mercury.
- Level the mercury to the top of the cell using a glass plate.
- Remove the mercury from the cell and measure its weight as M2.
Volume Calculation:
- Calculate the volume occupied by the cement bed within the cell using the equation:
Where D represents the density of mercury (13.54 g/cm³).
- Calculate the volume occupied by the cement bed within the cell using the equation:
Accuracy Check:
- Average at least two volume determinations that are within ±0.005cm³ to ensure accuracy and record this value.
(c) Determination of Apparatus Constant
Selection of Standard Cement:
- Select an amount (W) of standard cement to achieve a cement bed porosity of e=0.500. i.e. or
Preparation:
- Place a perforated disc on the cell’s ledge at the bottom and cover it with a new filter paper disc.
- Carefully place the weighed quantity of standard cement (W) into the cell, ensuring no loss occurs.
Cement Compression:
- Tap the cell to level the cement and add a second new filter paper disc on top of the leveled cement.
- Use the plunger to compress the cement until the plunger collar contacts the cell’s top.
- Slowly withdraw the plunger slightly, rotate it 900, repress the cement bed, and then slowly withdraw the plunger.
Manometer Setup:
- Connect the permeability cell to the manometer tube with an airtight connection.
- Gradually evacuate the air in the manometer U-tube until the liquid reaches the top mark, tightly closing the valve.
Measurement Process:
- Start the timer as the bottom of the meniscus reaches next to the top mark and stop it when the bottom of the meniscus reaches the bottom mark.
- Record the time (t) and the temperature during the test.
Repeat and Calculation:
- Repeat the entire procedure for two more samples of the same reference cement.
- Calculate the average time of the three determinations.
- Calculate the apparatus constant (K) using the provided formula below
K = 1.414 × S0 × ρ0 × (√0.1 * η0) / √t0
Where:
- K: Apparatus constant
- S0: Specific surface of reference cement
- ρ0: Density of reference cement
- t0: Mean of three measured times
- η0: Air viscosity at the mean of the three temperatures
0.1 is multiplied by n0 first, and then the square root is taken
(d) Determination of Fineness
Replication of Steps:
- Repeat steps 1 to 6 as performed in the determination of the apparatus constant, utilizing the cement sample whose fineness is to be assessed.
Fineness Calculation:
- After completing the procedure, calculate the fineness of the cement using the following formula:
\( S = \frac{521.08K\sqrt{t}}{\rho} \, \text{cm}^2/\text{g} \)
where
\( S \) = Specific Surface Area,
\( K \) = Apparatus Constant,
\( \rho \) = Density of Cement,
\( t \) = Time
Standard Specification
| Type of cement | Indian Standard Reference | Fineness Value (mm²/g) |
|---|---|---|
| OPC (33) | 269-1976 | 225,000 |
| OPC (43) | 8112-1989 | 225,000 |
| OPC (53) | 12269-1987 | 225,000 |
| Rapid hardening | 8041-1990 | 325,000 |
| Low heat cement | 12600-1989 | 320,000 |
| Portland slag cement | 455-1989 | 225,000 |
| PPC | 1489-1991 (Part 1) | 300,000 |
| High alumina cement | 6452-1989 | 225,000 |
| Super sulphated cement | 6909-1990 | 400,000 |
| IRS-T-40 | Railway Standard | 370,000 |
Precautions
Accurate Volume Calculation:
- Ensure precise and meticulous calculation of the volume occupied by the compacted cement bed within the cell. Maintain consistency in measurements to avoid discrepancies in results.
Precise Time Measurement:
- Exercise extreme care and precision in measuring the time taken by the manometer liquid to fall from one marked point to another. Accurate timing is critical for precise determination of the apparatus constant and subsequent calculation of cement fineness.
Consistency in Procedure:
- Maintain uniformity and consistency in following the testing procedure for each sample tested to ensure reliable and comparable results.
Cell Preparation:
- Thoroughly clean and prepare the permeability cell, ensuring there are no residues or irregularities that might affect the results.
Avoid Air Leaks:
- Ensure an airtight connection between the permeability cell and the manometer tube to prevent any air leaks that could influence the accuracy of the test.
Handling Cement Samples:
- Handle cement samples carefully during compression to avoid uneven packing or loss of material, ensuring consistent results.
Wagner Turbidimeter Method for Assessing Cement Fineness
Developed by L.A. Wagner, the turbidimeter method offers an estimation of the surface area of one gram of cement. This technique involves dispersing the cement uniformly in a rectangular glass tank filled with kerosene. Once dispersed, parallel light rays are directed through the solution, striking the sensitivity plate of a photoelectric cell.
Process of Wagner Turbidimeter Method
Cement Dispersion:
- Cement particles are evenly dispersed within the kerosene-filled tank, forming a suspension.
Light Ray Transmission:
- Parallel light rays are passed through the suspension, interacting with the suspended cement particles.
Turbidity Measurement:
- The turbidity, or cloudiness, of the solution is determined by measuring the current generated by the photoelectric cell. These readings reflect the turbidity of the solution caused by the suspended cement particles.
Data Collection:
- Readings are recorded at regular intervals while the cement particles settle in the solution. These readings provide insights into the grading in surface area and the size distribution of the particles.
Surface Area Estimation:
- The readings obtained through this method allow for the estimation of the surface area per gram of cement. This information aids in understanding the distribution and characteristics of cement particles.
Results Expression:
- The data collected from the Wagner Turbidimeter method is expressed in square centimeters per gram, providing valuable information about the surface area and particle size distribution of the cement sample.
Significance of Wagner Turbidimeter Method
The Wagner Turbidimeter method offers a non-destructive and efficient means to estimate the surface area of cement particles. This information aids in assessing the particle size distribution, aiding in understanding cement behavior during hydration and its subsequent impact on concrete properties.
F.A.Q.
Fineness test of Cement
Fineness in cement is crucial as it influences strength development, workability, hydration rates, and durability of concrete. Finer particles increase surface area, accelerating hydration and enhancing early strength.
There are several methods to test cement fineness. Common ones include the sieve method, Blaine’s air permeability method, and the Wagner turbidimeter method. Each assesses particle size distribution or surface area in different ways.
Various factors impact cement fineness, such as grinding techniques, clinker composition, grinding duration, additives, storage conditions, quality control measures, type of grinding aid used, particle size distribution, and the type of cement itself.
Measuring fineness ensures consistent quality in concrete production. It impacts strength, workability, durability, and overall performance of the concrete in various construction applications.
Specifications vary for different types of cement. For instance, Ordinary Portland Cement (OPC) typically has a specific surface area requirement of 225,000 mm²/g, while Rapid Hardening Cement might require 325,000 mm²/g.
